Name: DLE130M 130cc Electric Start Gasoline UAV Engine with Built-in Alternator
Brand: DLE
SKU: 262
Availability: InStock

Description

DLE130M Electric Start Gasoline UAV Engine with Built-in Alternator – 130cc Auto-Start & Power Supply System

The DLE130M is a high-performance 130cc twin-cylinder gasoline engine with electric start and integrated 14.5V 350W alternator—perfect for UAVs requiring autonomous ignition and onboard power generation.

Product Description

The DLE130M is an advanced twin-cylinder 2-stroke gasoline engine designed for professional UAVs and heavy-duty aerial platforms. Based on the proven DLE130 architecture, this upgraded version integrates both a planetary gear electric starter and a high-efficiency 350W alternator, offering a complete power solution for drones that demand reliability, autonomy, and onboard electricity.

With a power output of 13 horsepower at 8500 RPM and thrust support for 27–29 inch propellers, the DLE130M is capable of powering long-range missions, VTOLs, and hybrid drones. The built-in 14.5V alternator delivers a steady 350W @ 6000 RPM, supplying energy to avionics, flight controllers, or payloads during flight.

The planetary gear starting mechanism provides high torque and smooth startup, significantly reducing load and wear during ignition. Combined with its fuel efficiency and smooth throttle response, the DLE130M is a complete propulsion + energy system for modern UAVs.

Key Features

Integrated electric start with planetary gear system (12V 400W)
Built-in alternator: 14.5V output, 350W @ 6000 RPM
Delivers 13 HP @ 8500 RPM with 130cc twin-cylinder displacement
Compatible with large propellers: 27×12, 28×10, 28×11, 29×9
High compression ratio of 9.2:1 for strong combustion efficiency
Low vibration and reliable power delivery
Includes starter motor, rectifier, relay, and spark system
Ideal for long-endurance drones, VTOLs, hybrid UAV platforms

Specifications

Engine Type	Twin Cylinder, 2-Stroke
Displacement	130 cm³
Bore x Stroke	47 mm × 37.5 mm
Compression Ratio	9.2 : 1
Output Power	13 HP @ 8500 RPM
Idle Speed	1300 RPM
Recommended Propellers	27×12, 28×10, 28×11, 29×9
Spark Plug	DLE CM6
Lubrication Ratio	30:1 (92# unleaded gasoline + 2T oil)
Starter Motor Power	12V / 400W
Alternator Output	14.5V / 350W @ 6000 RPM
Weight (Engine + Muffler)	4200 g
Ignition + Spark Plug Weight	200 g
Relay Module Weight	160 g
Rectifier Weight	415 g

What’s Included

DLE130M Engine Unit with Electric Starter
Built-in Alternator & Rectifier
Ignition Module + 2x Spark Plugs (DLE CM6)
Exhaust Mufflers with Mounting Hardware
Relay, Connectors, Safety Accessories
Instruction Manual (PDF)

The DLE130 Autostart version is a high-performance twin-cylinder gasoline engine designed for large-scale RC aircraft and industrial UAV platforms. Equipped with an integrated electric starter and powerful 14V 350W alternator, it offers superior functionality, faster ignition, and reliable energy output for onboard systems.

This upgraded version adopts a planetary gear-driven starter system, which ensures higher starting torque and a smoother start-up process. The alternator allows real-time power generation during flight, supporting additional onboard electronics such as flight controllers, video transmitters, or lighting systems. With a compact and lightweight design, this engine is ideal for applications requiring efficient power and quick deployment.
